Vogt VH 30-90 S Set Pneumatic Chipping Hammer Renovation/Painter/Plasterer/Tiler Basic Set
Special Features
- For anyone who wants to professionally remove tiles and plasterwork!
- Anyone who still fundamentally removes plaster and tiles with electric hammers is not yet familiar with the VOGT hammer: the impact characteristics, the advanced tool, and the ergonomic working position lead to significantly higher surface performance and make it the perfect device for removing tiles.
- Thanks to the compressed air medium, the device is not only lighter but also much more durable: no dust-sensitive fan, no electronics. The large reach creates distance from falling material. This allows you to work at the full floor height without scaffolding; Our device is even ideal for removing plaster from ceilings.
- Thanks to its simple operation, the operator intuitively adjusts the tool, working pressure, and angle to the material thickness and hardness. Scrapers are required for plaster, coatings, and glued tiles, while chisels are needed for cement plaster or tiles in a mortar bed. The hammer loosens insulation panels, natural stone or ceramic panels, and effectively renovates sandstone walls and exposed masonry with the range of tools that has been optimized in practice over the years. Thanks to the newly developed dust extraction system (optional), harmful dust can be extracted directly from the chisel shaft. High-alloy steels and easily replaceable wear parts reduce operating costs to a minimum. The low air consumption is the result of the precisely fitting impact mechanism and even allows use with 230 V compressors.
Applications
- Interior plastering
- Component insulation
- Ceiling plaster
- Wall tiles
- Cement plaster
- Sandstone
- Masonry jointing
- Insulation
- Decorative plaster
- Floor tiles
Technical data
- Model VH 30-90
- Vibration damped Yes
- Length 90 cm
- Weight 4.5 kg
- Max. Number of strokes 3,200/min
- Operating pressure 3.0 - 6.0 bar
- Air consumption 190 l/min/6 bar
- Tool holder shank 14 mm
- Sound pressure emission level LPA 89.8 dB (+3 dB on.) / 6 bar
- Sound power level LWA 100.8 dB (+3 dB on.) / 6 bar
- Vibration value 6.5 m/s²
- Uncertainty 1.1 m/s²
Scope of delivery
- 1 Delta P blade M 410 UP
- 1 Wide tool M 340
- 1 Scraper holder M 5000
- 1 Scraper B 120 S
- 1 Adapter 3/4 inch to standard connection Z 200
- 1 Precision linseed oil gun Z 300
- 1 Compressed air hose 10 m
- 1 VOGT special oil 0.1 l
- 1 Ring wrench 15/19
- 1 Pair of work gloves
- 1 Safety glasses
- 1 Earplugs
- 1 Metal transport case
- 1 User manual
