Spectra GL622N Double Slope Laser (rechargeable)
Features
- The GL622N is a highly advanced slope laser from the inventors of the construction laser.
- Despite its many functions, this double slope laser can be operated almost blindly.
- The GL622N levels itself completely automatically, so setting it in a bubble is a thing of the past.
- New to this multifunctional slope laser is the control panel, which is intuitive to operate.
- Anyone can immediately get to grips with the GL622N without any prior knowledge.
- Furthermore, this slope laser is equipped with a large graphic display, allowing all functions to be operated quickly.
Double slope
- The Spectra GL622N is a construction laser with dual slope.
- This means that you can create a slope on two different sides.
- The GL622N even has the largest slope range in its class!
- With this slope laser, you can set the slope to within a thousandth of a percent, with a percentage of -25 to +25%.
- Steep slopes therefore pose no obstacle whatsoever.
Complete with RCN602N remote control
- The complete package of the Spectra GL622N is only fully complete with the right radio remote control.
- This latest slope laser from Spectra is therefore delivered as standard with the new RC602N radio remote control.
- Uniquely, this remote control is also equipped with a very large display.
- Thanks to the extra Thanks to a strong radio connection, you can wirelessly control all functions of the slope laser from a distance of up to 150 meters.
- That saves you quite a few meters of walking a day!
Highly advanced receiver
- The Spectra GL622N dual slope laser comes standard with the Spectra HL760 handheld receiver.
- This most advanced handheld receiver from the top American manufacturer of laser equipment enables a range of new applications.
- For example, this combination features the so-called PlaneLok function.
- This automatically locks the laser beam onto an existing elevation.
- The Fingerprint function is also unique.
- With this, the handheld receiver receives only the laser beam from the connected GL622N slope laser, without being interfered with by signals from other construction lasers in its reception area.
- Finally As a handy feature, we have the Grade Match function.
- This enables automatic slope transfer for measuring unknown elevation differences between two points over unfamiliar terrain and eliminating time-consuming slope calculations.
Technical Data
- Use: Outdoor
- Slope: Dual Automatic
- Diameter Range with Receiver: 800 meters
- Slope Range: -25 to +25 %
- Accuracy: ± 1.5 mm over 30 m
- Self-leveling: Yes
- Self-leveling Range: ± 5 degrees
- Rechargeable: Yes
- Power Supply: Battery Pack
- Battery Life: 35 hours or alkaline batteries
- Alkaline Battery Life: 40 hours
- Laser Class 2
- Out of range warning: laser stops rotating
- Tripod mount 2 x 5/8" (brass)
- Protection class IP67
- Drop resistance 1 meter onto concrete
- Dimensions (LxWxH) 240 x 150 x 270 mm
- Weight 3.64 kg
Standard included
- Case
- Spectra HL760 handheld receiver
- RC602N remote control
- Battery pack
- Charger
- Clear, Dutch-language manual
- Calibration certificate
