Scheppach HS100S Table Circular Saw 5901310905
The Scheppach HS100S table circular saw features a fold-out blade on both the left and right sides, a handwheel for adjustments, and various safety measures. The machine is supplied including two saw blades.
Special Features
- Powerful 2000 Watt motor
- Table extensions on both sides for expansion of the work surface
- Table height: 830 mm. Table dimensions: 563x583 mm
- Base with anti-slip feet
- Sawing height up to 85 mm
- Carbide saw blade Ø250mm
- Tilting saw blade 0-45°
- Heights and angles adjustable with handwheel
- Includes saw blade guard, 24-tooth saw blade (pre-assembled), 48-tooth saw blade, miter gauge and stop
Technical data
- Net weight (kg)20.14
- Length (mm)940
- Width (mm)642
- Height (mm)830
- Length of the contact surface (mm)642
- Saw blade bore (mm)30
- Minimum shaft speed (1/min)0
- Maximum shaft speed (1/min)5000
- Weight (kg)20
- Contact surface width (mm)940
- Power output (W)2000
- Max. swivel range (°)45
- Adjustable maximum cutting depth (mm)85
- Adjustable minimum cutting depth (mm)0
- Tilt adjustment left (°)0
- Tilt adjustment right (°)0
- Important features
- Nom. power consumption (W)2000
- Saw blade diameter (mm)250
- Voltage (V)230
- Cutting depth (90°) (mm)85
- Cutting depth (45°) (mm)65
Scope of delivery
- In box
- 2 Saw blades
- Miter fence
- Length fence
