Metabo 691154000 TS254M Table Circular Saw Set + Stand 254 mm 1500 Watt
Special Features
- Compact mobile table circular saw with good sawing performance and excellent working comfort
- Torsionally rigid tubular frame construction for very demanding requirements on the construction site and during assembly
Cables and all attachments can be stored on the housing - High tensile strength motor with electronic overload protection
- Motor brake for quick stopping of the saw blade in 3 seconds
- Restart protection: prevents accidental starting of the machine after a power interruption
- Soft start for long service life of motor and drive
- Finely adjustable parallel guide with double clamping and quick release
- Exact saw blade tilt via gear ring guide
- Automatic reset on 0-45° after concealed cut
- Easy saw blade change thanks to spindle lock
- Diverter knife tool-free lowering for concealed cuts and transport
- Precise, pull-out table top widening and extension for extra-large support surface
Technical data
- Dimensions 669 x 748 x 334 mm
- Working height 334 mm
- Sawing height 0 - 80 mm
- Max. sawing height 90°/45° 80 / 48 mm
- Max. sawing width on the parallel guide 520 mm
- Max. material width on the right-angle guide 195 mm
- No-load speed 4200 /min
- Sawing speed 56 m/s
- Saw blade 254 x 30 mm
- Saw blade tilt range -1.5 - 46.5 °
- Power input S1 100% 1500 W
- Weight 24.4 kg
- Cable length 2.3 m
- Noise emission
- Sound pressure level 92 dB(A)
- Sound power level (LwA) 105 dB(A)
- Measurement uncertainty K3 dB(A)
Standard included
- Carbide saw blade with interchangeable teeth (40-tooth)
- Base
- Parallel guide
- Right-angle guide
- Table extension
- Table widening (right)
- Push stick
