Leica Lino L2P5-1 Line and Point Laser 864431
Product Description
- The Leica Lino L2P5-1 point and line laser you can rely on.
- Convenient and simple to use.
- The Leica LINO L2P5-1 produces excellently visible lines precisely, quickly, and easily.
Special Features
- Projects horizontally, vertically, diagonally, above, below, left, and right
- Excellent visibility of laser lines
- Automatic level with high accuracy
- Only two buttons for very easy and intuitive use
- Lock function for angled line projection and transport protection
- IP54: robust and dust- and splash-proof
- Easily transfer measured points
- Range of 25 meters without receiver / 80 meters with receiver
- 2 laser lines / 4 laser points
- Accuracy 0.2 mm
- Self-leveling range: 4°
- Self-leveling time: < 3 s
- Laser line thickness at 5 meters: 2 mm
- Laser type: 635 nm / Class 2
- Battery type: Rechargeable Li-Ion (or AA 3 x 1.5V)
- Operating time: up to 44 hours with Li-Ion battery
- Storage temperature: -25 to 70 °C
- Operating temperature: -10 to 50 °C
- Lino thread: 1/4
- Wall clamp thread: 1/4 + 5/8
- Dimensions: 110 x 60 x 100
- Lightweight
Technical data
- Net weight (kg) 0.53
- Width 60 mm
- Depth 110 mm
- Height 100 mm
- Protection IP54
- Battery LI-ION RECHARGEABLE / AA 3 X 1.5V
- Range 25 M / 80M with laser receiver
- Self-setting Horizontal and vertical
Scope of delivery
- Leica Lino L2P5-1
- Guideline
- Magnetic, multifunctional adapter
- Tripod ball adapter
- Case
- Calibration report
