Holzstar TF200SE Milling machine with carriage and swiveling milling spindle
The improved version of the TF200E is now available!
Special features
- Aluminum carriage for easy workpiece feeding
- Heavy cast iron table with large working surface
- Cast iron milling spindle, swiveling from +5° to -45°
- Milling motor rotation direction right or left
- Variable speed with interchangeable belts
- Milling stop with fine adjustment
- Holder for safe workpiece guidance
- With angle stop and cover
Technical data
- Voltage V 3x400
- Motor power kW 3.9
- Spindle diameter mm 30
- Spindle inclination ° 5- -45
- Spindle length mm 100
- Working height mm 900
- Maximum tool diameter mm 180
- Rotation speed rpm 1800/3000/6000/9000
- Extraction nozzle mm 100
- Carriage dimensions mm 1000x240
- Weight kg 218.00
