Fischer Chemical Capsule RM II 14 for cracked concrete 539799 10 pieces
- The capsule system for cracked concrete without borehole cleaning.
- The fischer Chemical Capsule RM II in combination with Anchor Rod RG M is the first capsule system with European Technical Approval Option 1 for cracked concrete, which does not require borehole cleaning.
- With the Chemical Capsule, steel structures, machines, or stairs are anchored in indoor and outdoor areas.
- The Capsule can be used with the fischer Anchor Rod RG M and the fischer Internal Thread Anchor RG MI.
- With the Chemical Capsule RM II, no borehole cleaning is required; nevertheless, the anchor can still withstand very high loads, enabling fast installation.
Advantages
- The RM II is the first Capsule system with an Anchor Rod RG M or Internal Thread Anchor RG MI, which requires no borehole cleaning. This allows for faster work without compromising on quality.
- Additionally, there is less exposure to drilling dust on site. This increases safety for the user.
- The glass capsule is easy to use and particularly suitable for single anchorages and overhead mounting.
- Use in combination with the RG MI Internal Thread Anchor allows for multiple assembly and disassembly, thereby offering optimal flexibility.
Characteristic properties
- Chemical capsule system for anchoring in cracked concrete.
- Very quick to install without borehole cleaning.
- Secure anchoring of high loads.
- Ideal for single anchorages and overhead mounting.
- Very wide range of anchor rods and accessories available.
Applications
- Suitable for: Steel structures, Handrails, Stairs, Column bases, Machines, Masts, Removable fixings, Temporary fixings, e.g. for machines, Scaffolding fixings. Approved for: Overhead mounting Water-filled boreholes Construction materials
- Approved for: Concrete C20/25 to C50/60, cracked and uncracked Also suitable for: High-density natural stone The details (construction materials, loads, etc.) of the available approval apply.
- Approval ETA-16/0340 DoP No. 0090 - EN
Installation
- The Chemical capsule RM II, in combination with Anchor rod RG M or Internal thread anchor RG MI, can be used for through-hole mounting.
- The 2-component Chemical capsule RM II contains styrene-free vinyl ester resin and hardener.
- The fastening element must be installed using a rotary hammer in hammering-rotating mode and the corresponding mounting tool.
- During the installation of the anchor rod, the glass capsule is broken and, thanks to the rotary-hammering motion, the two components are mixed together, allowing the chemical reaction to take place.
- The mortar adheres to the borehole wall as well as the anchor rod, making the anchor one with the concrete.
Technical data
- Borehole diameter d0 16 [mm]
- Min. borehole depth h1 120 [mm]
- Min. anchoring depth hef 120 [mm]
- Suitable for RG M 14
Standard included
- 10 pieces
