Fischer 519781 Hollow wall plug HM 5 x 65 H with straight hook 50 pieces
The versatile metal hollow wall plugs with straight hook.
Features
- The fischer Metal hollow wall plug HM-H is a versatile hollow wall plug with a straight hook for all sheet materials.
- The plug is inserted using the fischer Hollow wall plug pliers HM-Z 1 in the pre-drilling method.
- With the pliers, the plug is pulled into the hollow space behind the sheet material.
- The arms spread out behind the sheet material and distribute the forces over a large surface area.
- Alternatively, manual installation is also possible.
- The fischer Metal hollow wall plug HM-H is particularly suitable for mounting lighting, pictures, and light wall shelving in interior construction.
Advantages
- Thanks to the extensive range, is The HM is suitable for sheet material with a thickness of 3-50 mm, allowing it to be used for numerous applications.
- The attachment part can be mounted and dismounted multiple times thanks to the metric internal thread.
- This makes the HM very flexible.
- The spreading arms of the HM ensure a large contact surface, enabling high loads.
- The barbs under the collar of the plug penetrate the sheet material, preventing the plug from rotating in the drill hole and guaranteeing secure mounting.
Key features
- Complete with hook. Flexible during installation: the screw can be loosened and tightened again.
- Does not rotate: The wings (claws) on the edge of the plug hold it firmly in the sheet material.
- Holds even heavy objects in sheet material due to the large contact surface of the spreading arms.
- Suitable for front-drill mounting.
Building materials
- Gypsum board and gypsum fiber boards Channel boards Lightweight wood wool boards Chipboard Plywood
Applications
- Paintings Lamps Small shelves Towel racks Mirror cabinets Curtain rails Substructures
Installation
- The HM hollow wall plug is suitable for front-drill mounting
- The fastener must be selected based on the thickness of the sheet material so that the arms can spread out over the largest possible surface area.
- Spread during installation the arms extend and press against the back of the sheet material.
- The HM can be mounted with mounting pliers.
- When using a cordless screwdriver or screwdriver, you must first remove the pre-assembled screw.
- When screwing in and spreading the arms, the mounting part or sheet thickness of a maximum of 6 mm must be used to prevent the hollow wall plug from rotating in the drill hole.
Technical data
- Drill hole diameter: 10 mm
- Sheet thickness 20 - 34 mm
- Plug length 65 mm.
- min. drill hole depth 71 mm.
Standard included
- 50 pieces
