Fein 90701009000 Vise set including aluminium jaw guards 110 mm
Magnetic vise with a clamping jaw width of 100 mm. FEIN VersaMAG Vise Set including aluminium jaw guards. Compact and powerful permanent magnet with vise for tool-free clamping of PLS components on magnetic surfaces. Includes FEIN VersaMAG protective jaw pair (P) Prisma 110 mm and protective jaw pair (B) Blank 110 mm made of aluminium. No scratches on the material - Highest quality even with sensitive workpieces such as stainless steel, aluminium or plastics.Special features
- Set of protective jaws (P) Prisma and (B) Blank Aluminium: Effortless clamping of flat material thanks to the upper 90° groove. No scratches on the material - highest quality, even with sensitive workpieces such as stainless steel, aluminium, or plastic. No wobbling or slipping of the workpiece thanks to the protective jaws. The FEIN premium quality of the protective jaws guarantees durability while simultaneously protecting the material. Saves finishing time and increases productivity on sensitive workpieces.
- Mobile, flexible, and quick to use. Adapts to any workplace thanks to a compact design and extra-narrow permanent magnet.
- Optimizes every workplace: neat and safe working in every application. Modular system: the unique modular system ensures secure maintenance in the most pressing work situations and can be permanently complemented by suitable accessories.
- Alignment précis de l’aimant permanent à l’aide d’une magnétisation of 30%.
- L’étau a 108 mm greenhouse with a large 100 mm spill.
- Coffret L-BOXX 238 with insert adapted for the FEIN VersaMAG set with a 100 mm large spill. Clair, ordonné et bien rangeé. Thank you for inserting small pieces, adding accessories to your place and the coffrets L-BOXX to your accessories and accessories.
Technical data
- Clamping width: 108 mm
- Clamping jaw height: 40 mm
- Clamping jaw width: 100 mm
- Magnetic holding force: 7,800 N
- Magnetic base dimensions: 212 x 70 mm
- Weight according to EPTA: 10.95 kg
Scope of delivery
- 1 permanent magnet
- 1 mounting plate
- 1 vise
- 1 Allen key 3 mm
- 1 lashing strap
- 2 aluminium protective clamping jaws B (plain)
- 2 aluminium protective clamping jaws P (prism) up to Ø 30 mm
- 1 plastic case (L-BOXX 238)
- 1 inlay FEIN VersaMAG vice set
