Facom 440.30 Combination Wrench OGV 30 mm
Special features
- Standard wrench for all normal applications
- High-quality mechanical properties combined with compact dimensions, with aviation industry requirements in mind
- Ring head: - The design of the ring angle (E-side) provides better grip on consecutive or countersunk nuts. - 12-point ring with OGV® profile for powerful torque without damaging the nut. Suffix H = 6-point ring. - Ring head bent 15°
- Fork head: - Fork bent 15°. - Optimized geometric ratio between the fork and the handle for greater accessibility
- Finish: chrome-plated, satin-finished
Technical data
- Wrench size: 30 mm
- Length: 340 mm
- Thickness E: 11.2 mm
- Thickness E1: 17.1 mm
- Thickness E2: 11.5 mm
- Head width B: 65 mm
- Head width B1: 43.5 mm
