Cub Cadet LR2 NR76 Ride-on Mower 76 cm
Special Features
- Compact with the power of a large tractor: The Cub Cadet MINI-RIDER LR2 NS76 combines the performance of a lawn tractor with an exceptionally compact size – ideal for medium to large gardens with limited storage space.
- Hydrostatic drive with foot pedal control: Enjoy smooth and stepless driving comfort thanks to the hydrostatic system, easy to operate with a foot on the pedal.
- REVTEK™ reverse mowing function: Thanks to Reverse Mowing Technology, you can mow safely in reverse – handy in tight spaces, provided there are no children or animals nearby.
- Intelligent Parking Assistance (IPA): Controlled reversing with 50% speed reduction, ideal for precise parking in sheds or garages.
- Comfort & ergonomics: The deluxe Seat, telescopic handlebar, and soft-grip steering wheel ensure maximum working posture and driving comfort.
- LED lighting: Equipped as standard with powerful LED headlights for extra visibility in twilight.
- Equipped with a convenient 200 L grass catcher bag
Benefits
- Powerful engine: 420 cc Cub Cadet OHV with full pressure lubrication and oil filter
- Large lawn capacity: Up to 2,500 m²/h mowing capacity thanks to the 76 cm wide cutting deck
- 2-in-1 mowing system: Mulching or side discharge
- Easy operation: Manual cutting deck control and 5 cutting height settings (38–95 mm)
- Safe & stable: Low vibration, maximum pedal grip, robust steel frame
- 200L grass catcher bag
Technical specifications
- Engine type Cub Cadet OHV
- Capacity (cm³) 420
- Engine/power (kW/min-1) 8.2 / 3000
- Cylinders Single
- Tank capacity (Capacity) (l) 4.9
- Lubrication Full pressure lubrication with screw-on oil filter
- Drive Hydrostatic
- Speed (max) Infinitely variable
- Speed control Foot pedal
- Lawn area (m²/h) 2500
- Cutting width 76
- Cutting height 38–95 mm
- Cutting options 2-in-1
- Number of blades 1
- Mower deck control Manual lever control
- Cutting height setting 5
- Cleaning nozzle on mower deck/Mulch kit Standard/Standard
- Grass collection bag (Capacity) (l) / accessory no. Optional 115 liters/(19A30014OEM)/(19A30014OEM)
- Basket opening/ hardtopg – / –
- Fill indicator / Grass Deflector / Grass Deflector – / Standard
- Grass collection bag (Capacity) (l) Optional 115 liters/(19A30014OEM)
- Front axle Steel
- Front bumper No
- Min. Turning circle (cm) (cm) 46
- Wheels f/r (inches) 13 x 5 / 16 x 6.5
- Wheel bearings Plain bearings
- Step-through frame Easy step-through frame
- Battery 12 V wet battery 115 CCA
- Headlights LED
- Seat type Seat High Comfort Deluxe
- Seat adjustment Screw
- Steering wheel Standard
- Reverse mowing (RevTEK) Standard
- Battery charger No
- LpA / LwA / LwAg (dB) (dB) 88 / 98 / 100
- Body vibration value (k-factor) (K-Factor) (m/s²) 1 / 0.5
- Hand-arm vibration value (K-Factor) (m/s²) 5 / 1.5
- Dimensions (L / W / H) (cm) 157 / 85 / 112
- Weight (net) (kg) 127
Scope of delivery
- 1× Cub Cadet LR2 NS76 ride-on mower
- 1× Mulch kit (standard fitted)
- 1x Grass catcher
- Delivered on pallet (semi-assembled)
