Bosch Blue 0601063R05 GLL 3-80 C Line Laser Set 1x12V 2.0 Ah and Fast Charger GAL 12V-40 CV in L-BOXX

Special Features

  • Highly accurate CAL Guard monitoring and remote use with Bluetooth®-connected smartphone app
  • High visual clarity is provided by powerful diodes
  • 3 x 360° lines for simultaneous horizontal and vertical leveling for very efficient work

Technical Data

  • Product Width: 84 mm
  • Product Height: 148 mm
  • Mailing Segment: Metal, Stone, and Wood
  • Dust and Splash Water Protection: IP54 *** (***except the Li-Ion battery and AA1 battery adapter)
  • Power supply: 12 V Li-Ion battery|4 x 1.5 V LR6 (AA)
  • Self-leveling time, typ.: 4 s
  • Leveling range: ± 4°
  • Laser class: 2
  • Laser diode: Line: 630 - 650 nm, < 10mW
  • Tripod thread: 1/4", 5/8"
  • Working range, approx.: up to 30 m
  • Length x width x height: 162 x 84 x 148 mm
  • Leveling accuracy: ± 0.2 mm/mᵃ/**
  • Working range, value: 30m
  • Storage temperature: -20 – 70°C
  • Operating temperature: -10 – 40°C
  • Laser line color: Red
  • Operating time, max.: 8 h (Li-Ion) and 6 h (4 x AA) in 3-line mode
  • Working range with receiver, value: 120 m
  • Working range with receiver: up to 120 m
  • Projection: 3 x 360° line
  • Compatible laser receivers: LR 6 + 7

Scope of delivery

  • L-BOXX 136 (1 600 A01 2G0)
  • Universal holder BM 1 Professional (0 601 015 A01)
  • Laser target plate
  • Case
  • 1x battery GBA 12V 2.0Ah (1 600 Z00 02X)
  • Holder for laser receiver LR 6/7 (1 608 M00 C1L)
  • Laser receiver LR 7 Professional (0 601 069 J00)
  • Fast charger GAL 12V-40 Professional (1 600 A01 9R3)
