Bessey STE370 Ceiling and Mounting Bracket with Pump Handle 2070 - 3700 mm 350 kg
Special features
- Loadable up to a maximum of 350 kg with the telescopic pole fully retracted
- Extremely stable construction thanks to high-load steel tubes and non-slip PVC contact surfaces
- One-hand operation thanks to 2-component plastic handle with pump mechanism
- Quick-release button for quickly extending and retracting the telescopic pole
- Adjustable holding force by rotating the bracket on the handle
- Also usable in inclined positions thanks to the contact surfaces that swivel steplessly from -45° to +45°
Extremely secure grip
- The bracket guarantees a reliable, secure grip: thanks to extremely stable construction for a maximum load capacity of 200 kg – depending on the respective support size – with a maximum extension length thanks to rubber PVC contact surfaces above and below thanks to the anti-slip protection integrated into the handle
Versatile use
- It is possible to position and hold a wide variety of materials: thanks to the stable construction of the steel tube in three sizes – extendable up to 3.70 m thanks to 9 x 7 cm support plates with a swivel range of -45° to +45°
Precise and fast operation
- The support can be precisely adjusted to the requirements and safely released: by fixing in three steps: To pre-set the ceiling prop, press the release button and extend the telescopic inner tube to the desired length. Fine adjustment is done by the Operate the pump handle until the mounting plate of the support is in contact with the workpiece. Then turn the handle clockwise until the desired holding force is reached (note the maximum load capacity) by releasing in two steps: First, turn the ceiling prop counterclockwise. As soon as there is no more holding force, press the release button to retract the inner tube.
Technical data
- Adjustment range 2070 - 3700 mm.
- Load capacity max. 75 kg. (350 kg)
- Weight 4.10 kg.
Standard included
- 1 piece
