Airpress HL 215-6 Compressor 8 bar 1.5HP 230 Volt
Features
- The H 215-6 compressor is an oil-free compressor equipped with a universal quick coupling
- The compressor is compact and weighs 10 kg.
- The oil-free compressor features a 1.5 hp/1.1 kW motor, has 1 cylinder, and has a speed of 3450 RPM.
- The switch-on pressure is 6 bar, the maximum pressure is 8 bar, and the compressor has an effective capacity of 92 l/min.
- With the pressure reducing valve, identifiable by the red rotary knob, you can quickly and easily set the desired working pressure, which can be read on the manometer on the left.
- The pressure in the pressure vessel can be read on the manometer on the right. read.
Technical data
- Weight (kg) 10.00
- Dimensions (mm) 380 x 300 x 330
- Load (work/rest %) 20/80
- Start Direct
- Drive Direct driven 1:1
- Cylinders 1
- Voltage (V) 230 V / 50 Hz / 1 Ph
- Pressure vessel Yes Pressure vessel capacity (l) 6
- Galvanized pressure vessel No
- Suction capacity (l/min) 126
- Effective capacity (l/min) 92
- Effective capacity (m3/h) 5.52
- Switching pressure (bar) 6
- Maximum pressure (bar) 8
- Noise level dB(A) (0 m) 96
- Noise level dB(A) (4 m) 76
- Noise level dB(A) (7 m) 71
- Noise-dampened No
- Air connection (⅛) EURO/ORION
- Number of air connections 1
- Number of reducible air connections 1
- Stages 1
- Oil-free Yes
- Pump speed (RPM) 3450
- Power (HP/kW) 1.5 hp / 1.1 kW
Scope of delivery
- In box
- Manual
